Thermal Monocular ThermTec Cyclops 335 SE

ThermTec Cyclops 335 SE Thermal Monocular

The ThermTec Cyclops 335 SE is the latest thermal monocular in the Cyclops series, combining excellent image quality, advanced AI features and user-friendly operation. A NETD <20 mK sensor and 35 mm lens enable detection of targets up to 1800 meters, making it suitable for both open terrain and dense woodland.

High performance and image clarity
The 384×288 @ 12 μm thermal sensor delivers sharp, detailed images even with minimal temperature differences. A 3.3×–13.2× magnification range allows precise target observation.

AI calibration and image stability
Self-learning AI algorithms continuously collect environmental data and optimize image quality and background rendering in real time, ensuring a consistently stable view.

Fast start-up and long battery life
The device powers on in just 3 seconds. The built-in high-capacity Li-ion battery (2×18650) provides up to 16 hours of continuous operation.

Accurate distance estimation and easy handling
AI-based distance measurement improves target assessment, even with multiple objects in view. Joystick control enables comfortable one-handed use with an intuitive interface.

Technical Specifications – Cyclops 335 SE

• Resolution: 384 × 288
• Pixel pitch: 12 μm
• NETD: <20 mK @300K
• Spectral range: 8–14 μm
• Frame rate: 50 Hz
• Detection range: up to 1800 m
• Objective lens: 35 mm / F1.0
• Field of view: 7.5° × 5.6°
• FOV @100 m: 13.2 × 9.9 m
• Optical magnification: 3.3×
• Digital zoom: 1×–4× continuous
• Eye relief: 40 mm
• Exit pupil: 6 mm
• Diopter adjustment: ±5 D
• Display: AMOLED
• Display resolution: 1024 × 768
• Display size: 0.39″
• Color palettes: 6
• Viewing modes: Forest / Target / Outline
• Photo & video recording: Yes
• Language support: Multilingual
• Internal memory: 64 GB
• Calibration: Automatic / Manual
• PIP: Yes
• AI / MIL distance measurement: Yes
• Heat tracking: Yes
• Real-time notifications: Yes
• OSD recording: Yes
• Battery: Built-in Li-ion (2×18650)
• Battery life: up to 16 h
• Operating temperature: –20 °C to +50 °C
• Protection rating: IP67
• Weight: 522 g
• Dimensions: 196.4 × 63.8 × 64.1 mm
